27-1126/02
Category:
Soils
Sub Category:
Compaction and CBR, CBR
Product Group:
Versa-Loader
Includes Platen Assembly, 10,000 lb. capacity S-Type Load Cell, 50 mm Displacement Transducer, Penetration Piston, GDU and DS7.2.
Compatible with Versa-Loader, Tritest 50, CBR-Test 50 and MultiPlex 50 Load Frames.
110vAC, 50/60 Hz, 1ø.
| Calibration, °F | english, metric |
| ASTM D1883 | Yes |
| AASHTO T193 | Yes |
| Description | CBR Data Logging Test |
24-9175
Includes lower platen, penetration piston assembly, dial indicator with 1.0” range 10,000 lb capacity proving ring and mounting hardware.
24-9185
Includes Platen Assembly, 10,000 lb. capacity S-Type Load Cell, 50 mm Displacement Transducer and Penetration Piston. Compatible with Versa-Loader, Tritest 50, CBR-Test 50 and MultiPlex 50 Load Frames. Data Logger and Aquisition Software sold separately.
24-9177
Includes lower platen, penetration piston assembly, dial indicator with 25 mm range 45 kN capacity proving ring and mounting hardware.
27-1124/02
Includes: 2-channel digital readout, 10,000 lb capacity S-type load cell, penetration transducer with 2" range, penetration piston and mounting hardware
27-1125/02
Includes: 2-channel digital readout, 45 kN capacity S-type load cell, penetration transducer with 50 mm range, penetration piston and mounting hardware
