DS7.2 CU/CD Triaxial Shear Strength Program for Windows 7, 32/64 bit

« return

DS7.2 CU/CD Triaxial Shear Strength Program for Windows 7, 32/64 bit

27-1763

Category:

Data Logging, Software and Electronic Instrumentation, Soils

Sub Category:

Geotechnical Testing Software, Electronic Instrumentation, DataSystem Software

Product Group:

DS7.2 CU/CD Effective Stress Triaxial Software, DS7.2 for Windows 7

• Complete package for consolidated drained and consolidated undrained triaxial tests

This advanced package includes procedures for consolidated drained and consolidated undrained tests. Standard options are available for saturation, consolidation and shearing with automatic monitoring of the various parameters through transducers linked to the system. Load, strain, volume-change, pore-pressure, cell pressure and back pressure can all be monitored. Various prints and graphical plots are available to the engineer and include saturation data such as pore pressure build-up and B values, consolidation, volume change against time, shearing load versus strain with pore pressure monitoring.

Description DS7.2 CU/CD Triaxial Shear Strength Program for Windows 7, 32/64 bit
GDU Compatability Yes
DSU Compatability No

Minimum PC System Requirements

•Computer: IBM-compatible PC

•Disk Space: Minimum of 1 Gbyte free hard disk space

•RAM: Minimum of 2 Gbyte

•Processor: 2GHz minimum*

•Screen: 1024 x 768 for best results, or higher

•System Software: Windows™ 7 and XP (SP3)

•Net Framework 4 (included)

•For full advantage of the advanced reporting facilities, Microsoft

Word (Version 2007 or 2010) should be resident on the system.

* (Note : AMD processors not supporting SSE2 are not compatible.

These include all AMD ‘Socket A’ parts)
