Electronic Type Universal Testing Machines

Electronic Type Universal Testing Machine 300 kgf (3kN)

ELE's series of UTM's test physical characteristics of various materials such as metal, plastic, bio, composite materials, wire, paper and film, rubber, small automobile parts, electronic equipment, aerospace, fibre etc.

Features:

• Single column electro mechanical table top model
• High precision load cell
• 1/50,000 force resolution /0.01mm/min speed accuracy
• 0.01~500mm/min speed
• Overload protection limit sensor
• Emergency power cut off button
• Up to 4 step division of force capacity for more detailed readings

Software features:

• Close loop. Control of load, displacement, extension, stress and strain.
• Remote control via software, text execution, data analysis available through RS-232 port
• Software updates and modification installation available via email or remote support
• Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc.
• 15+ different Testing Methods including cyclic, creep, relaxation, keeping etc.
• View data and graphs of previously ran tests
• Determine and analyze data points such as yield point, breaking point, modulous etc.
• Raw data analysis for detailed test data
• Exportable to excel and customizable to show user required data
• Test report printing options include direct to printer or excel file export.
• Test report data can be configured to show only necessary data and to exclude unused data.

Electronic Type Universal Testing Machine 2000 kfg (20 kN)

36-2416/05 is a material property tester for test of physical characteristics of various materials such as metals, plastics, bio, composite materials, wire, paper and film, rubber, automotive, small parts, electronic equipment, aerospace, fiber etc. The ELE UTM series provides the process of test, analysis of data and various test result suited to the tester's requirements. The 36-2416/05 is a light table top model with a maximum capacity of 20kN able to test rubbers, films, paper, tape, plastic, fibers etc. Capable of testing tensile, compression, bending, shear, tear, peel etc. Testing standards such as ISO, ASTM, KS, JS, BS.

• Dual column electro mechanical table top model
• High precision load cell, class 1 and class 0.5 calibration
• 1/100,000 force resolution / 0.01mm/min speed accuracy
• 0.01~500mm/min speed (up to 1000mm/min option)
• Up to 4 step division of force capacity for more detailed reading
• Overload protection limit sensor, non-contact extension limit sensor
• Emergency power cut off button

Electronic Type Universal Testing Machine 3000 kgf (30kN)

36-2417/05 is designed to serve the requirements of laboratories, research and development, quality control, manufacturers and educational fields. Hard plastics, metals, composites, wood, rope etc are ideal specimens for 36-2417/05. Tests methods such as tensile, compression, bending, peel, shear, puncture etc are available.

Features:

• Dual column electro mechanical floor standing model
• High precision load cell, class 1 and class 0.5 calibration
• 1/50,000 force resolution
• 0.05~500mm/min
• Up to 4 step division of force capacity for more detailed reading
• Overload protection limit sensor, non-contact extension limit sensor
• Emergency power cut off button

Software features:

• Close loop. Control of load, displacement, extension, stress and strain
• Remote control via software, text execution, data analysis available through RS-232 port
• Software updates and modification installation available via email or remote support
• Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc
• 15+ different Testing Methods including cyclic, creep, relaxation, keeping etc
• View data and graphs of previously ran tests
• Determine and analyze data points such as yield point, breaking point, modulous etc
• Test report printing options include direct to printer or excel file export
• Test report data can be configured to show only necessary data and to exclude unused data
• Raw data analysis for detailed test data
• Exportable to excel and customizable to show user required data

Electronic Type Universal Testing Machine 30,000 kgf (300kN)

36-2418/05 is designed to serve the requirements of laboratories, research and development, quality control, manufacturers and educational fields. Hard plastics, metals, composites, wood, rope etc are ideal specimens for 36-2418/05. Tests methods such as tensile, compression, bending, peel, shear, puncture etc are available.

Features:

• Dual column electro mechanical floor standing model
• High precision load cell, class 1 and class 0.5 calibration
• 1/50,000 force resolution
• 0.1~500mm/min (1000mm/min max optional)
• Up to 4 step division of force capacity for more detailed reading
• Overload protection limit sensor, non-contact extension limit sensor
• Emergency power cut off button

Software features:

• Close loop. Control of load, displacement, extension, stress and strain
• Remote control via software, text execution, data analysis available through RS-232 port
• Software updates and modification installation available via email or remote support
• Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc
• 15+ different Testing Methods including cyclic, creep, relaxation, keeping etc
• View data and graphs of previously ran tests
• Determine and analyze data points such as yield point, breaking point, modulous etc
• Test report printing options include direct to printer or excel file export
• Test report data can be configured to show only necessary data and to exclude unused data
• Raw data analysis for detailed test data
• Exportable to excel and customizable to show user required data

Electronic Type Universal Testing Machine 5000 kgf (50kN)

36-2423/05 is designed to serve the requirements of laboratories, research and development, quality control, manufacturers and educational fields. Hard plastics, metals, composites, wood, rope etc are ideal specimens for 36-2423/05. Tests methods such as tensile, compression, bending, peel, shear, puncture etc are available.

Features:

• Dual column electro mechanical floor standing model
• High precision load cell, class 1 and class 0.5 calibration
• 1/50,000 force resolution
• 0.05~500mm/min
• Up to 4 step division of force capacity for more detailed reading
• Overload protection limit sensor, non-contact extension limit sensor
• Emergency power cut off button

Software features:

• Close loop. Control of load, displacement, extension, stress and strain
• Remote control via software, text execution, data analysis available through RS-232 port
• Software updates and modification installation available via email or remote support
• Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc
• 15+ different Testing Methods including cyclic, creep, relaxation, keeping etc
• View data and graphs of previously ran tests
• Determine and analyze data points such as yield point, breaking point, modulous etc
• Test report printing options include direct to printer or excel file export
• Test report data can be configured to show only necessary data and to exclude unused data
• Raw data analysis for detailed test data
• Exportable to excel and customizable to show user required data

Electronic Type Universal Testing Machine 10,000 kgf (100kN)

36-2424/05 is designed to serve the requirements of laboratories, research and development, quality control, manufacturers and educational fields. Hard plastics, metals, composites, wood, rope etc are ideal specimens for 36-2424/05. Tests methods such as tensile, compression, bending, peel, shear, puncture etc are available.

Features:

• Dual column electro mechanical floor standing model
• High precision load cell, class 1 and class 0.5 calibration
• 1/50,000 force resolution
• 0.05~500mm/min
• Up to 4 step division of force capacity for more detailed reading
• Overload protection limit sensor, non-contact extension limit sensor
• Emergency power cut off button

Software features:

• Close loop. Control of load, displacement, extension, stress and strain
• Remote control via software, text execution, data analysis available through RS-232 port
• Software updates and modification installation available via email or remote support
• Diverse and robust configurations for automatic test end options, graph options, PID values, crosshead movement speeds etc
• 15+ different Testing Methods including cyclic, creep, relaxation, keeping etc
• View data and graphs of previously ran tests
• Determine and analyze data points such as yield point, breaking point, modulous etc
• Test report printing options include direct to printer or excel file export
• Test report data can be configured to show only necessary data and to exclude unused data
• Raw data analysis for detailed test data
• Exportable to excel and customizable to show user required data
