2401E
Category:
Soils
Sub Category:
Compaction and CBR, CBR
Product Group:
Field CBR
Set Includes:
EI24-9290. Field CBR Jack x 1
EI24-9300. Ball Seating Attachment x 1
EI78-0460. Proving Ring, 2,250 lb. (10 kN) cap. x 1
EI78-0760. Proving Ring, 6,000 lb. (28 kN) cap. x 1
EI24-9183. Field Penetration Piston x 1
EI24-9308. Extension Rod x 1
EI24-9188. Bracket and Adapter x 1
EI24-9312. Bridge Support x 1
EI88-4110. Penetration Dial Indicator x 1
EI24-9245. Circular 5 lb. (4.54 kg) Surcharge Weight x 1
EI24-9246. Slotted 10 lb. (4.54 kg) Surcharge Weight x 1
EI24-9248. Slotted 20 lb. (9.07 kg) Surcharge Weight x 1.
| Weight, lbs | 137.8 |
| ASTM 4429 | Yes |
| Description | Field CBR Test Set, Metric |
2400E
Set Includes: EI24-9290. Field CBR Jack x 1EI24-9300. Ball Seating Attachment x 1EI78-0460. Proving Ring, 2,250 lb. (10 kN) cap. x 1EI78-0760. Proving Ring, 6,000 lb. (28 kN) cap. x 1EI24-9183. Field Penetration Piston x 1EI24-9308. Extension Rod x 1EI24-9188. Bracket and Adapter x 1EI24-9312. Bridge Support x 1EI88-4100. Penetration Dial Indicator x 1EI24-9245. Circular 5 lb. (4.54 kg) Surcharge Weight x 1EI24-9246. Slotted 10 lb. (4.54 kg) Surcharge Weight x 1 EI24-9248. Slotted 20 lb. (9.07 kg) Surcharge Weight x 1.
